Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90
![Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [0]](https://www.blackseasuppliers.ro/jq/server/php/files/8479/attr/24543/2/Mono%204-6%20kW-fullimg.jpg "Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [0]")
![Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [1]](https://gomagcdn.ro/domains3/nzen.ro/files/product/medium/pompa-de-caldura-r32-monobloc-6-kw-hyundai-hyhc-v6w-d2n8-be30-486457.jpg "Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [1]")
![Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [2]](https://www.blackseasuppliers.ro/jq/server/php/files/8481/3/Schema-%20Control%20APP%20Pompa%20de%20caldura%20R32%20monobloc%20Hyundai.jpg "Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [2]")
![Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [2]](https://gomagcdn.ro/domains3/nzen.ro/files/product/original/pompa-de-caldura-r32-monobloc-6-kw-hyundai-hyhc-v6w-d2n8-be30-486457.jpg "Pompa de caldura R32 MONOBLOC 12 kW (3x380V) HYUNDAI HYHC-V12W/D2RN8-BER90 [2]")
Putere (kW): 12
Tip bransament: Trifazat
Agent frigorific: R32
Durata de livrare: 5-7 zile lucratoare
- Descriere
- Review-uri (0)
Pompe de caldura aer-apa MONOBLOC
- freon ecologic R32
- compresor BLDC Inverter sistem de inalta performanta
- functionare extrem de silentioasa
- complet echipate cu pompa de circulatie, vas expansiune, supapa siguranta
- functie WIFI integrata cu control la distanta (smartphone)
- functionare pana la -25 grade Celsius
- temperatura agent termic pana la 65 grade Celsius
- functionare in cascada pana la 6 unitati
- functie preparare rapida ACM
- functie antilegionela (desinfectie boiler)
- posibilitate de control a 2 zone de incalzire
| CARACTERISTICI TEHNICE | |
| Incalzire (A7/W35) | 12,10 kW |
| P electrica absorbita (A7/W35) | 2,44 kW |
| COP (A7/W35) | 4,95 |
| Incalzire (A7/W45) | 12,30 kW |
| P electrica absorbita (A7/W45) | 3,32 kW |
| COP (A7/W45) | 3,60 |
| Incalzire (A7/W55) | 11,90 kW |
| P electrica absorbita (A7/W55) | 3,90 kW |
| COP (A7/W55) | 3,05 |
| Racire (A35/W18) | 12 kW |
| - P electrica absorbita (A35/W18) | 3,04 kW |
| - EER (A35/W18) | 3,95 |
| Racire (A35/W7) | 11,50 kW |
| P electrica absorbita (A35/W7) | 4,18 kW |
| EER (A35/W7) | 2,75 |
| Clasa eficienta sezoniera LWT 35C: | A+++ |
| Clasa eficienta sezoniera LWT 55C: | A++ |
| Compresor: | BLDC Inverter |
| Incarcare din fabrica refrigerent R32 | 1,75 kg |
| Pompa circulatie | de tip inverter |
| Presiune maxima | 9 mCA |
| Vas expansiune (Volum) | 8 l |
| Racorduri hidraulice | 1 1/4 " |
| Rezistenta electrica (back-up) | 9 kW |
| Plaja temperatura apa- Racire | 5~30 °C |
| Plaja temperatura apa- Incalzire | 25~70 °C |
| Plaja temperatura apa- Apa Calda Menajera | 30~65 °C |
| Alimentare electrica | 3 x 380/50 V/Hz |
| Putere sonora EN12102-1 | 65 dB/A |
| Plaja temperatura exterioara- Racire | -5~43 °C |
| Plaja temperatura exterioara- Incalzire | -25~35 °C |
| Plaja temperatura exterioara- Apa Calda Menajera | -24~43 °C |
| Tip | Trifazat |
| CARACTERISTICI CONSTRUCTIVE | |
| Masa neta | 160 kg |
| Dimensiuni (lxHxA) | 945x1385x530 mm |
WIFI control
- descarcati aplicatia “COMFORT HOME” din APP STORE sau GOOGLE PLAY sau scanati codul QR de pe cutia controllerului
- dupa care va inregistrati urmand pasii descrisi in manual
- aplicatia functioneaza pe Android 7.0 si IOS7, sau versiuni mai noi
- aplicatia permite vizualizarea statusului pompei de caldura, modul de operare
- setarile de temperatura precum si consumul de energie si sugestii pentru consum redus.
Pliante si manuale
